SN74LVC574APWR Electronic Components IC FF D TYPE SNGL 8BIT 20TSSOP
产品详情
SN74LVC574APWR IC FF D-TYPE SNGL 8BIT 20TSSOP
| function | standard |
| type | TYPE D |
| the output type | trimorphism, non-inverted |
| the number of components | 1 |
| number of bits per component | 8 |
| clock frequency | 150 MHz |
| MAXIMUM PROPAGATION DELAY AT DIFFERENT V, MAXIMUM CL | 6.8ns @ 3.3V,50pF |
| the trigger type | positive edge |
| current - output high, low | 24mA,24mA |
| voltage - power supply | 1.65V ~ 3.6V |
| Current - Quiescent (Iq) | 10 µA |
| input capacitance | 4 pF |
| operating temperature | -40°C ~ 125°C(TA) |
| the installation type | surface mount type |
| supplier device package | 20-TSSOP |
| encapsulation/housing | 20-TSSOP (0.173", 4.40mm width) |
| basic product number | 74LVC574 |
