D45VH10G Transistor Bipolar BJT Single Through Hole TO-220 electronics ic chips
产品详情
D45VH10G Transistor Bipolar BJT Single Through Hole TO-220 electronics ic chips
| TYPE | DESCRIBE |
|---|---|
| category | Discrete ductor Products Transistor - Bipolar Transistor (BJT) - Single |
| manufacturer | onsemi |
| series | - |
| product status | in stock |
| Transistor Type | PNP |
| Current - Collector (Ic) (Maximum) | 15 A |
| Voltage - Collector Emitter Breakdown (Max) | 80 V |
| Vce saturation voltage drop at different Ib, Ic (maximum) | 1V @ 800mA,8A |
| Current - Collector Cutoff (Maximum) | - |
| DC current gain (hFE) at different Ic, Vce (minimum) | 20 @ 4A , 1V |
| Power - max | 83 W. |
| frequency-transition | 50MHz |
| Operating temperature | -55°C ~ 150°C(TJ) |
| installation type | through hole |
| Package/Enclosure | TO-220-3 |
| Supplier Device Packaging | TO-220 |
| Basic product number | D45VH10 |
