ISO7741BDWR General Purpose Digital Isolator Electronic IC Chip 16-SOIC
产品详情
ISO7741BDWR General Purpose Digital Isolator Electronic IC Chip 16-SOIC
| TYPE | DESCRIBE |
|---|---|
| category | Isolator digital isolator |
| manufacturer | Texas Instruments |
| series | ISO774x |
| product status | in stock |
| technology | capacitive coupling |
| type | Universal |
| Isolated power | none |
| number of channels | 4 |
| Input - Side 1/Side 2 | 3/1 |
| channel type | unidirectional |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 85kV/µs |
| data rate | 100Mbps |
| Propagation delay tpLH / tpHL (max) | 16ns,16ns |
| Pulse width distortion (max) | 4.9ns |
| Rise/Fall Time (Typical) | 2.4ns,2.4ns |
| Voltage - Powered | 2.25V ~ 5.5V |
| Operating temperature | -55°C ~ 125°C |
| installation type | Surface Mount Type |
| Package/Enclosure | 16-SOIC (0.295", 7.50mm wide) |
| Supplier Device Packaging | 16-SOIC |
| Basic product number | ISO7741 |
