LM321MFX/NOPB SOT23-5 Low Power Single-Channel Operational Amplifier Original SMD IC Chip
产品详情
LM321MFX/NOPB SOT23-5 Low Power Single-Channel Operational Amplifier Original SMD IC Chip
| Attributes | parameter value |
|---|---|
| Product catalogue | Operational Amplifier |
| Op amp type | General Purpose |
| Number of amplifier groups | 1 |
| Gain Bandwidth Product (GBP) | 1MHz |
| Slew Rate (SR) | 0.4V/us |
| output type | - |
| voltage | 3V~30V,±1.5V~15V |
| Supply current of each channel | 660μA |
| Operating temperature | -40℃~85℃ |
| Amplifier Type | General |
| Number of Circuits | 1 |
| Slew Rate | 0.4 V/µs |
| Gain Bandwidth Product | 1MHz |
| Current - Input Bias | 45nA |
| Voltage - Input Offset | 2mV |
| Current - Power Supply | 660µA |
| Current - Output/Channel | 40mA |
| Voltage - Power Supply, Single/Dual (±) | 3 V ~ 30 V, ±1.5 V ~ 15 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package/Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
