TL062CN CP TL062CDR CT SOP/DIP-8 Low Power JFET Input Operational Amplifier
产品详情
TL062CN CP TL062CDR CT SOP/DIP-8 Low Power JFET Input Operational Amplifier
| Attributes | parameter value |
|---|---|
| Product catalogue | FET input op amp |
| Op amp type | J-FET |
| Number of amplifier groups | 2 |
| Gain Bandwidth Product (GBP) | 1MHz |
| Slew Rate (SR) | 3.5V/us |
| output type | - |
| voltage | 7V~36V,±3.5V~18V |
| Supply current of each channel | 200μA |
| Operating temperature | 0°C ~ 70°C |
| Amplifier Type | J-FET Number of Circuits 2 |
| Slew Rate | 3.5 V/µs |
| Gain Bandwidth Product | 1MHz |
| Current - Input Bias | 30pA |
| Voltage - Input Offset | 3mV |
| Current - Power Supply | 200µA |
| Voltage - Power Supply, Single/Dual (± ) | 7 V ~ 36 V, ±3.5 V ~ 18 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package/Case | 8-SOIC (0.154", 3.90mm wide) |
| Supplier Device Package | 8-SOIC |
